Induction motor SEMh56-4A
single-phase380 Valuminium

Induction motor - SEMh56-4A - Cantoni Motor - single-phase / 380 V / aluminium
Induction motor - SEMh56-4A - Cantoni Motor - single-phase / 380 V / aluminium
Add to favorites
Compare this product
Go to the Cantoni Motor website for more information

Characteristics

Type
induction, single-phase
Voltage
380 V
Configuration
aluminium
Protection class
IP55, IP54
Number of poles
4-pole
Cooling mechanism
IC411
Applications
industrial
Other characteristics
IEC
Power

40 W
(0.05 hp)

Intensity

0.6 A

Torque

0.28 Nm
(0.206517 ft.lb)

Rotational speed

1,390 rpm
(8,733.6276 rad.min-1)

Operating temperature

40 °C
(104 °F)

Description

Breakdown torque ratio [ 2.4 Starting current ratio [ 1.5 Frequency [Hz] 50 Rated output [HP] 0.06 Service factor [ 1.0 Efficiency at rated (full) load [ 35.0% Duty S1 Synchronous speed [rpm] 1500 Rated torque [Nm] 0.28 Power factor at rated (full) load [ 0.85 Starting torque ratio [ 1.6 Frame size 56 Terminal box position top Starting method DOL Possibility of terminal box rotation yes Insulation class F Bearing on D-side 62012Z Bearing on ND-side 62012Z Mounting arrangement IMB3/B5/B35/B14 Bearings regreasing no Housing - material aluminium
