Induction motor SEh90-2L
single-phase380 Valuminium

Induction motor - SEh90-2L - Cantoni Motor - single-phase / 380 V / aluminium
Induction motor - SEh90-2L - Cantoni Motor - single-phase / 380 V / aluminium
Add to favorites
Compare this product
Go to the Cantoni Motor website for more information

Characteristics

Type
induction, single-phase
Voltage
380 V
Configuration
aluminium
Protection class
IP55, IP54
Number of poles
2-pole
Cooling mechanism
IC411
Applications
industrial
Other characteristics
IEC
Power

2 kW
(2.72 hp)

Intensity

13 A

Torque

6.87 Nm
(5.067052 ft.lb)

Rotational speed

2,780 rpm
(17,467.2552 rad.min-1)

Operating temperature

40 °C
(104 °F)

Description

Breakdown torque ratio [ 1.4 Winding connection - Starting current ratio [ 2.5 Frequency [Hz] 50 Rated output [HP] 2.8 Service factor [ 1.0 Efficiency at rated (full) load [ 74.0% Duty S1 Synchronous speed [rpm] 3000 Power factor at rated (full) load [ 0.99 Starting torque ratio [ 0.4 Frame size 90 Terminal box position top Starting method DOL Possibility of terminal box rotation yes Insulation class F Bearing on D-side 62052Z Bearing on ND-side 62052Z Mounting arrangement IMB3/B5/B35/B14 Bearings regreasing no
