Cartesian palletizer and depalletizer CUBE 1000

for palletfor bottlesfor glass containers

We introduce CUBE, an extremely compact, economical and versatile case palletizer. Thanks to its self-supporting structure with wheels, the equipment can be easily moved at the factory to service any line. In addition, it can be installed in places with low ceilings since it does not have a telescopic arm. Main advantages of the equipment: - Maximum speed: 10 boxes / minute. - Maximum box weight: 16 Kg (*) - Dimensions: 2480 x 1600 x 2750mm (*) - High ceilings are not necessary. - Self-supporting structure with wheels. - Maximum palletizing height 1950mm (*) - Built-in Stand-By system to improve energy efficiency. - Low consumption <10 KW. - System for catching the box by means of a vacuum. - It incorporates a telecare system. - Edit your programs easily and store up to 100 different programs. - 10.1 ”industrial screen, multi-language. - Includes production control with the main indicators (total running time, total stoppage time, cycle time, etc.). - Protections in perforated sheet Steel or polycarbonate, to choose. - Includes height-adjustable conveyor with box centering. - Head collision sensor. - Detection of open box both from the top and bottom. - Pallet detector for quick change by the operator. - Security system to avoid cash los in the evento of voltaje losses or emergency stops. - Multicolor and audible beacon for warning at the end of the pallet or alarms. And much more…. (*) Doesn't it suit your needs? Don't worry, we are automation specialists and any adaptation is posible! Protect Your Workers From Injury!
