Concrete floor grinder CF-246.2

planetarythree-phaseelectric

Product description
The CF-246.2 surface milling machine cuts a shallow grooving profile into floors using parallel diamond cutting discs (grooving). It restores slip resistance on single and flat joints as well as on paved concrete floors by creating consistent, flat grooves.

Functions & Features

• Powerful Kohler diesel engine compliant with Stage V emissions
• Milling shaft with precision high-performance bearings
• Finely adjustable electro-hydraulic lift and lowering of the machine via a rocker mechanism
• Pressurized water connection with GEKA coupling and shut-off valve
• Blade cooling via multiple water jets arranged in parallel to the milling shaft
• Operating hours counter

Technical data
Max. cutting depth: 10 mm
Max. blade Ø: 300 mm
Blade bore: 60 mm + 3 holes
Blade mounting side: central
Max. clamping width: 400 mm
Max. engine power: 17.7 kW / 24 hp
Net engine power: 15.4 kW
Engine type: Diesel
Engine model: Kohler KDW 1003
Engine start: Electric start
Cutting depth adjustment: Hydraulic
Feed: Hydrostatic
Dimensions L/W/H (Transport): 1447 / 1014 / 1229 mm
Weight: 1000 kg

Characteristics / Technical specifications

• Max. cutting depth: 10 mm
• Max. blade Ø: 300 mm
• Blade bore: 60 mm + 3 holes
• Blade mounting side: central
• Max. clamping width: 400 mm
• Max. engine power: 17.7 kW / 24 hp
• Net engine power: 15.4 kW
• Engine type: Diesel
• Engine model: Kohler KDW 1003
• Engine start: Electric start
• Cutting depth adjustment: Hydraulic
• Feed: Hydrostatic
• Dimensions (Transport) L/W/H: 1447 / 1014 / 1229 mm
• Weight: 1000 kg
