DC motor driver MCM

The MCM is designed to drive a variety of brushed motors. This is the CM version of our IMCM. The overload-proof 4-quadrant chopper outputs voltages between 5.5V to 16V up to a constant load of 16A (32A peak). The PWM can be set between 1kHz and 20kHz. The module is protected against undervoltage and overvoltage, shuts down automatically when overheating and is also equipped with a linear current limiting. Furthermore, protection for cross-conduction is integrated. Additional features are reversal of rotation direction, revolution counter and brake to V+ or GND.
