Power quality analyzer CVM-A1500

for electrical networksgraphic

The CVM‑A1600 is a high-performance power quality analyzer designed for monitoring and recording quality in medium- and low-voltage installations. In addition to measuring, calculating, recording, and displaying the main electrical parameters, it logs power quality events detected in voltage and current along with their waveforms. Electrical parameters and quality events are measured and calculated in accordance with IEC 61000‑4‑30, 3rd edition, and the device ensures strict compliance with IEC 62586‑2 testing methods. As a power analyzer, it also calculates electrical efficiency parameters such as active and reactive power, THD (%), TDD (%), harmonics up to the 63rd order, imbalance, crest factor, and other quality parameters such as flicker and the k factor. Its touchscreen lets you navigate through all configuration and parameter display screens. Instantaneous, historical, and recorded quality event values can all be viewed. The built-in web server enables remote access to instantaneous and historical parameters, as well as device configuration. The primary application of a Class A-certified power quality analyzer according to IEC 61000‑4‑30 is to measure and record voltage and current quality at the installation’s connection point, in order to detect disturbances or quality issues that could cause equipment failures or production downtime.
