CNC bending machine 302 CN3.1V

electro-hydraulicservo-electrictube

Model 302 CN3.1V represents the state of the art of the cnc technology, that makes possible to curve part with COMPLEX GEOMETRY. The CNC control three axis enables to roll MULTIPLE RADII a single profile, making is easy to obtain repeatability and accurate parts, with a precision unattainable with machine of lower segment quality. This cnc automatic bending rolls equipment opens a multitude of new possibilities for a large number of sectors: LIGTING INDUSTRY ADVERTISING SIGNALS GREENHOUSES HOME and URBAN FURNITURE design industry PLAYGROUND and AMUSEMENT PARK BIMINI TOP FOR BOATS Model 302CN3.1V can operate in horizontal and in vertical position. Availability of rolls for bending round pipes and modular rolls for all common shape of profiles. Obviously special rolls set could be supplkied for the special profile and extruded aluminum bars. The CNC controls SIMULTANOEUOSLY 3 AXIS : the profile feeding and the two bending rolls. It's EASY TO USE and PROGRAMMING. The section feeding is referenced by a roller encoder kept in contact with the section by pneumatic cylinder. The machine is equipped with an electronic profile detector of automatic alignment of the bar and rotary axis reset at start of the cycle. Cad drawing in DXF format can be imported on the CNC control. The CNC integrates a remote desktop application program to establish a communication in REMOTE CONTROL for software SUPPORT. It's available in other different bending capacities and can bE chosen between AC motors or brushless motor according the parts to be rolled. It's possible to customize the machine with additional tools and additional axis controlled.
