Fully-automatic filler RTA 100
tin canfor the food industryrotary

fully-automatic filler
fully-automatic filler
Add to favorites
Compare this product


Characteristics

Operational mode
fully-automatic
Container type
tin can
Domain
for the food industry
Type
rotary
Other characteristics
PLC-controlled, high-speed
Throughput

1,000 p/min

Description

The machine is suitable for filling in tinplate cans 072.8 mm format of integers Peeled tomatoes with minimal damage to the product. Specifications Machine It is a fully automatic rotary machine, designed for filling of tinplate containers. All parts of the machine in direct contact with the product are stainless steel and non-toxic materials in compliance with current regulations. The filling operation is performed in the following manner: The introduction of the boxes is done by a synchronization of the auger and a port inlet star inside the machine, a central star transports the same along the fill path. In particular, the machine having a large diameter, allows for a more homogeneous distribution of the product, promoting the high quality, excellent filling and high-speed (1000 CPM). Once completed filling an exit star brings the boxes on the conveyor, here the action of a twist vibrator, with partial overturning of the box, settles and removes excess product. A recovery mat carries the product to an uphill mat that brings him back to the tank. The machine is supplied with a CE standard outside cabin, with PLC, inverter and the function switches, as well as speed controllers. An electrical panel on board the machine, with viewer to control functions, controls the operation of the same.
