Hot runner system Ciject® One

The Ciject One features an unrivalled level of control with simplicity of operation. Features include: Purpose designed resin and 316 stainless steel catalyst/hardener piston pumps for high reliability and simple maintenance Advanced seal technology which prevents leaks without the need for lubrication Unique pivoted pump mounting that allows easy access to entire pump assembly for easy maintenance Available with mix ratios to suit polyester/vinylester, epoxy or phenolic systems Fully enclosed cabinet with full operator control 110 - 240V industrial micro-electric PLC control with colour touch-screen operator display Injection pressure range -1 to 9 Bar (G) Programmable injection quantities and speeds 20 pre-settable programs Automatic mix-head mounted on adjustable boom Unique catalyst/hardener monitoring system Catalyst system that includes return isolation valve to provide additional security Alarm monitored injection ‘pause’ control which enables operator to safely stop/start during the injection process Alarm monitored ‘gel timer’ which indicates when flushing is required Low volume, non-pressurized mix-head flush system to ensure simple and quick cleaning Storage area for hardener and solvent Stainless steel resin drum platform optimized for easy loading of standard resin barrels Inline resin filter allowing cleaning without removing the loading hose from material Catalyst filtration which also allows cleaning Training and technical assistance available on request Solvent Level Sensor Non-intrusive solvent level sensor that detects if level is insufficient for operation Prevents start-up and warns operator if level is low
