Impact crushing and screening plant JS-3

mobileprimaryhigh-capacity

CONSTMACH JS-3 Mobile Crushing plant is a perfect solution for crushing low-middle hard materials such as limestone, riverstone, dolomite, basalt etc. JS-3 is the result of advanced design and engineering, usage of premium quality components with long-lasting and excellent craftsmanship. JS-3 Mobile Crushing & Screening Plant includes double chassis and it is combination of: 1st chassis: Feeding Hopper with vibrating feederCJC-110 Primary Jaw CrusherBy-pass conveyor (for extraction of soil)Feeding ConveyorWheeled mobile chassis with hydraulic legsDust Removing System 2nd chassis: CSI-1215 Secondary Impact CrusherVibrating Screen with 3 decksFeedback Conveyor from vibrating screen to secondary impact crusherFold-up type Stockpile ConveyorsWheeled mobile chassis with hydraulic legsAutomation System with PLC and remote controller for whole systemDust Removing SystemDiesel Electric Generator Set (Optional Application) JS-3 production capacity changes between 250 to 300 tph according to hardness grade of the material to be crushed. Maximum feeding size is 850 x 600 mm. Thanks to special design of the secondary impact crusher, produced final materials have a satisfying fine material ratio and also excellent cubical shape which is a desired result especially for concrete production. It is possible to get 3 or 4 different fractions at the same time. In case of need, it is possible to adapt an electric generator to chassis of the plant.
