Air pressure regulator Type 710 seriesdiaphragmsingle-stageindustrial
Add to favorites
Compare this product
Characteristics
- Product
- for air
- Technology
- diaphragm
- Number of stages
- single-stage
- Applications
- industrial, precision, pneumatic
- Other characteristics
- high-flow
- Pressure
Max.: 17 bar
(246.56 psi)Min.: 0 bar
(0 psi)- Orifice diameter
0.25 in, 0.38 in, 0.5 in
- Temperature
Max.: 66 °C
(150.8 °F)Min.: -18 °C
(-0.4 °F)
Description
The Type 710BP Back Pressure Regulator is a high flow, highly accurate pneumatic relief valve with an adjustable set point. It’s primary function is to provide protection against over pressurization in the downstream portion of a pneumatic system. This precision unit is capable of handling flows up to 50 SCFM. A rolling diaphragm provides the sensitivity that causes the Type 710BP to vent to atmosphere in response to the slightest upstream changes.
Catalogs
Short Form Catalogue
8 Pages
