Touchpad for medical applications TPP-55A1A6for industrial applicationsfor marine applicationsfor OEM
Add to favorites
Compare this product
Characteristics
- Domain
- for industrial applications, for OEM, for medical applications, for marine applications
- Material
- glass, PET
- Protection level
- waterproof, IP65, rugged
- Mounting
- panel-mount
- Other characteristics
- USB, precision
Description
Product description
Drawing on years of industrial trackball expertise, Cursor Controls Ltd developed the TPP Series panel-mount touchpad to deliver precise, solid-state cursor control in demanding environments. The mutual-capacitance sensing engine supports conventional X/Y tracking with multi-finger gesture input and plug-and-play USB connectivity.
The module is engineered for front-of-panel mounting in OEM keyboards and consoles. Its sealed design (IP65), choice of overlay materials and simple construction enable easy cleaning, decontamination and low-maintenance operation in wet, dirty or otherwise harsh conditions.
Features
Typical Applications
Technical specifications
Drawing on years of industrial trackball expertise, Cursor Controls Ltd developed the TPP Series panel-mount touchpad to deliver precise, solid-state cursor control in demanding environments. The mutual-capacitance sensing engine supports conventional X/Y tracking with multi-finger gesture input and plug-and-play USB connectivity.
The module is engineered for front-of-panel mounting in OEM keyboards and consoles. Its sealed design (IP65), choice of overlay materials and simple construction enable easy cleaning, decontamination and low-maintenance operation in wet, dirty or otherwise harsh conditions.
Features
- Solid-state mutual-capacitance touch sensing engine
- Output: USB (plug-and-play)
- Sealing rating: IP65
- Haptic and audible feedback (function specific)
- Multi-finger gesture support
- Eight capacitive touch feature buttons (standard)
- Smooth operation in rugged environments
- Tolerant to moisture, water and liquid contaminants
- Standard overlay options: glass and polyester
- Custom feature button configurations and overlays available
Typical Applications
- Industrial consoles
- Medical systems
- Marine systems
- Custom keyboard applications
- OEM custom solutions
Technical specifications
- Series: TPP (TPP Series panel-mount touchpad)
- Touchpad size shown: 6 inch
- Tracking technology: mutual-capacitance, solid-state
- Cursor axes: X and Y conventional tracking
- Output protocol: USB (plug-and-play)
- Sealing rating: IP65
- Feedback: Haptic and audible (function specific)
- Feature buttons: 8 capacitive touch feature buttons (standard)
- Gesture support: Multi-finger gestures supported
- Mounting: Front-of-panel mount for OEM keyboards/consoles
- Overlays available: Glass and polyester options (grey examples shown)
- Environmental tolerance: Designed for rugged environments; tolerant to moisture, water and liquid contaminants; easy to clean/decontaminate
- Customisation: Custom feature button configurations and overlays available
- Ordering code prefix: TPP (configurable suffix/options via product configuration)
