The vacuum technology allows hydrogen peroxide full penetration into the widest variety of packaging. Vacuum system is designed to allow the most effective sterilization phase and gas removal at cycle end.
The sterilisation or decontamination cycles work in an open loop, without any consumable, and grant a high level of repeatability.
Thermo-labile finished products in blister can be fully sterilised in the most recessed cavities.
DESIGN & CONSTRUCTION:
Capacity :from 500 lts. up to few cubic meters (other sizes available on request)
semi-automatic hinged doors or automatically sliding doors
chamber execution in highly satin finish AISI 316L stainless steel
direct ventilation in chamber with magnetic coupling fan to improve hydrogen peroxide circulation
open loop configuration with catalyst (no consumables) on exhaust
Process reliable and fully validable
Enhanced extraction of residual H2O2
Low H2O2 consumption
The process is extremely fast.
Savings on filter elements and ventilation systems
The final elimination of peroxide in the room does not provide for the impact on HVAC filters: in fact, there are no air flows for the degassing of the machine that impact on the company’s ventilation systems.
The DLVHP / ST is equipped with a catalyst for the elimination of H202 residues: there is no need consumables and no maintenance costs for components replacement.
- Terminal sterilization of packaging, even outside a classified area.
- Heat-sensitive Surgical Kits.
- Another field of application where until now the ETO or Gamma Rays were the only solution as prosthesis for implant and medical devices
