Module support CF-25bracketfor cutting machinesaluminium
Add to favorites
Compare this product
Characteristics
- Applications
- bracket, module, for cutting machines
- Material
- aluminium
- Other characteristics
- adjustable, wall-mounted, swivel, rotary, screw-in
Description
Product overview
This aluminum laser mount is designed to position and secure laser modules with an inner mounting diameter of ∅25.15 mm. It provides effective heat dissipation and precise mechanical adjustment for industrial CNC installations, including wall-mounted setups used in stone-cutting machines. The CF-25 bracket is compatible with Delta F Series and allows fine alignment via an M4 hex screw.
Key features
Technical data
Applications and compatibility
This aluminum laser mount is designed to position and secure laser modules with an inner mounting diameter of ∅25.15 mm. It provides effective heat dissipation and precise mechanical adjustment for industrial CNC installations, including wall-mounted setups used in stone-cutting machines. The CF-25 bracket is compatible with Delta F Series and allows fine alignment via an M4 hex screw.
Key features
- Adjustable X-axis movement: 150 mm
- 360° rotation of the laser head for full angular alignment
- Precise emission regulation with M4 hex screw
- Aluminum construction for improved thermal conduction
- Designed for wall mounting and integration into CNC stone-cutting systems
Technical data
- Material: Aluminum
- Compatible lasers: Delta F Series
- Laser head rotation: 360° precise rotation
- X-axis movement: 150 mm
- Inner mounting diameter: ∅25.15 mm
- Base thickness: 4 mm
- Adjustment: M4 hex screw
Applications and compatibility
- Wall mounting for CNC machines (stone cutting)
- Integration with Delta F Series laser modules
- Industrial positioning requiring precise angular and axial adjustments
