Industrial vacuum cleaner FROG

liquidsoil and chipsingle-phase

Il FROG is the industrial vacuum of the OIL line designed to separate and vacuum oil and swarf from the tanks of CNC machines. The standard equipment of this vacuum cleaner enables the cleaning operations to be speeded up and the oil lubricants-coolants to be reused. In the Oil and Swarf range, Depureco uses the “reverse flow” system to empty liquids. This system eliminates any additional maintenance and risks arising from the pumps clogging when transferring liquids. Suction is generated by two motors that work in parallel and ensure maximum speed. The FROG industrial vacuum is equipped with a 130-liter bin containing a quick-release metal basket that is used to separate the solid part from the liquid part. The 150-micron filter ensures a more effective filtration on the swarf. The electrical level indicator inside the container stops the airflow upon reaching maximum capacity. The FROG is supplied as standard with the perfect oil accessories kit for vacuuming CNC machines. SUCTION UNIT The vacuum is generated by 2 by-pass motors. Each motor is managed by an independent switch, permitting the operator to control the intake performance. The motors are located in a sturdy casing, with an insulating sponge to maintain a low noise level. INLET The vacuumed material enters the machine through a flanged intake nozzle located on top of the vacuum's lid and is then filtered by the metal mesh basket inside. The grid is paired with a PPL filter. The liquid is then collected inside the large tank. FILTERING ELEMENT The collected liquid goes through a PPL filter with a 150µ efficiency. Thanks to it it's possible to separate even the smallest solid particles,
