Office shelving
combinedcantileververtical storage

Office shelving - DEXION - combined / cantilever / vertical storage
Office shelving - DEXION - combined / cantilever / vertical storage
Office shelving - DEXION - combined / cantilever / vertical storage - image - 2
Office shelving - DEXION - combined / cantilever / vertical storage - image - 3
Office shelving - DEXION - combined / cantilever / vertical storage - image - 4
Office shelving - DEXION - combined / cantilever / vertical storage - image - 5
Office shelving - DEXION - combined / cantilever / vertical storage - image - 6
Add to favorites
Compare this product

Characteristics

Application domain
office
Type
cantilever, vertical storage, combined, horizontal storage
Inventory management
dynamic
Configuration
modular
Material
galvanised steel
Other characteristics
high-rise, longspan
Capacity

Min.: 1,500 kg
(3,306.9 lb)

Max.: 6,900 kg
(15,211.9 lb)

Height

1,500 mm, 2,000 mm, 2,500 mm, 3,000 mm
(59.06 in, 78.74 in, 98.43 in, 118.11 in)

Width

Min.: 1,200 mm
(47.24 in)

Max.: 3,000 mm
(118.11 in)

Depth

Min.: 400 mm
(15.75 in)

Max.: 1,200 mm
(47.24 in)

Description

With our Longspan shelving's modular design, and fast and easy assembly you can achieve the maximum possible storage capacity, regardless of the space you have available. The Longspan Shelving system allows for the easy adjustment of storage heights and configurations as your requirements change; providing a system that moves and changes with you. Longspan is equally suited for warehouse and office environments; easily configurable for a number of different applications. From low level hand-loaded shelving, to high-rise systems. Incorporating varying frame and beam sizes, customising the system for your exact needs is really straightforward. Medium- and Longspan bays can be combined in the same rack, and a bolt-free, lock-in system ensures support beams remain in position. Longspan frames are manufactured from pre-galvanised steel and beams are powder-coated grey white (RAL 9002) or orange (RAL 2001). Our Longspan shelving has been designed and tested to comply with the recommendations of the FEM Shelving Design Code 10.2.06.

Catalogs

No catalogs are available for this product.

See all of DEXION‘s catalogs
*Prices are pre-tax. They exclude delivery charges and customs duties and do not include additional charges for installation or activation options. Prices are indicative only and may vary by country, with changes to the cost of raw materials and exchange rates.
