• Brushless DC motor drive quickly accelerates the rotor to set speed
• Quiet working, Low noise ≤56dB
• D2012 is proven by IEC/EN 61010-1
• D2012 Plus passed the rigorous explosion-proof test and accredited with CE, cTUVus, FCC certificates, and MCA test. MCA test according to IEC/EN61010-2-20
Max. RCF : 15100×g, increment: 100×g
Speed Accuracy : ±20rpm
Rotor Capacity : 0.2mL/0.5mL/1.5mL/2mL×12
Run Time : 30sec-99min/Continuous
Driving Motor : Brushless DC motor
Safety Devices:
Door interlock,
Over-speed detection,
Over-temperature detection, Automatic internal diagnosis
Power: Single-phase, AC100V-240V
50Hz/60Hz, 3A ,100W
Noise level : ≤54dB
Acceleration/Braking time : 11s↑/9s↓
Dimension[D×W×H] : 255×245×140mm
Weight : 6kg
Certification : EMC, CE, FCC, ICES, cTUVus, CB
Advanced features: Speed/RCF switch,Short-time run function,sound-alert function
