Brushless motor D90L96-WC

DC20 V90 V

D90L96-WC Water-cooled Brushless Outrunner Motor 23KW D90L96 Outrunner Brushless Motors are designed for high performance gearless use, and are ideal for applications where rapid acceleration and high speed are called for. Diameters at 90mm Configuration: 24N20P Outrunner Speeds up to 14,070 rpm Maximum output power up to 23KW Maximum Torque output up to 26N*m High-power density Quanly Outer rotor brushless motors use a compact design with an external rotor that provides smooth, stable rotation. These motors are capable of achieving higher torque than its counterpart inner rotor designs. The higher inertia produced by external rotor motors makes them ideal for applications that require lower noise and reliable performance at high speeds. Hobiba Brushless DC Electric Motor (BLDC) are designed for high performance gearless use. Applications like efoil, e-surfboard, eSUP, hydrofoiling, boat, and racing competition ATV(All-Terrain Vehicle), Go-kart,QUad Bike...and so on. Can be customized for Sensor or sensorless Winding Current Shaft Options Cable and Connector Kv Ratings Mounting Options Encoder or Non
