3-axis CNC milling center VMC M8
5-axis4-axisvertical

3-axis CNC milling center - VMC M8 - Duomi (Guangdong) Intelligent Equipment Co., Ltd - 5-axis / 4-axis / vertical
3-axis CNC milling center - VMC M8 - Duomi (Guangdong) Intelligent Equipment Co., Ltd - 5-axis / 4-axis / vertical
3-axis CNC milling center - VMC M8 - Duomi (Guangdong) Intelligent Equipment Co., Ltd - 5-axis / 4-axis / vertical - image - 2
3-axis CNC milling center - VMC M8 - Duomi (Guangdong) Intelligent Equipment Co., Ltd - 5-axis / 4-axis / vertical - image - 3
3-axis CNC milling center - VMC M8 - Duomi (Guangdong) Intelligent Equipment Co., Ltd - 5-axis / 4-axis / vertical - image - 4
3-axis CNC milling center - VMC M8 - Duomi (Guangdong) Intelligent Equipment Co., Ltd - 5-axis / 4-axis / vertical - image - 5
3-axis CNC milling center - VMC M8 - Duomi (Guangdong) Intelligent Equipment Co., Ltd - 5-axis / 4-axis / vertical - image - 6
Add to favorites
Compare this product

Characteristics

Number of axes
3-axis, 5-axis, 4-axis
Spindle orientation
vertical
Machined material
for steel, for copper, for brass, for aluminum
Structure
with rotary table
Spindle mount
BT 30
Number of tool stations
12 tools
Applications
for the automobile industry, for the aerospace industry, for molds, medical
Other characteristics
high-precision
X travel

800 mm
(31.5 in)

Y travel

700 mm
(27.56 in)

Z travel

330 mm
(12.99 in)

Rotational speed

Min.: 1,000 rpm
(6,283 rad.min-1)

Max.: 30,000 rpm
(188,496 rad.min-1)

Power

11 kW
(14.96 hp)

Work feed X-axis

20 m/min

Work feed Y-axis

20 m/min

Work feed Z-axis

20 m/min

Table load capacity

800 kg
(1,764 lb)

Positioning accuracy

0.003 mm
(0.00012 in)

Repeatability

0.003 mm
(0.00012 in)

Tool-changing time

2 s

Weight

4 t
(4.41 us ton)

Overall length

2,200 mm
(86.6 in)

Overall width

2,500 mm
(98.4 in)

Overall height

2,400 mm
(94.5 in)

Description

Versatile CNC Milling Machine for Precision Metalworking and Custom Parts Engraving with VMC M8 Optional Features: Coolant Through Spindle Chip Conveyor Oil Mist Separator Oil Skimmer We also provide additional machine accessories and tools, including: Tool Holders Collets Cutting Tools Application Areas: Graphite or Copper Electrode Machining: Supports efficient machining of electrode materials, ensuring high precision and surface quality. Model Sample Production: Can be used for making shoe molds, automotive parts molds, and other prototypes. Surface Engraving & 3D Machining: Capable of 2D/3D engraving, relief carving, and complex surface machining. Technical Parameters: X/Y/Z Maximum Moving Speed: 24 m/min X/Y/Z Servo Motor Power: 1.3 kW Worktable & Load Capacity: Worktable Size: 800 × 700 mm Machine Specifications: CNC Controller: LNC / SYNTEC
