Speed low - 9 km/h
Speed high - 23 km/h
Speed high (EEC countries) - 20 km/h
Compaction
Rolling width - 1800 mm
Tyre overlap - 42 mm
Wheel loads, without ballast - 1480 kg
Wheel loads, with wet sand ballast - 2170 kg
Wheel loads, with max. ballast - 3000 kg
Tyre pressure, min - 250 kPa
Tyre pressure, max - 850 kPa
Tyre type (smooth) - 11.00 - 20
Water spray system, type - Pressurized
Water spray system, tank capacity - 415 l
Water spray system, spray nozzle - one per tyre
Ballast volume - 2.4 m3
Engine
Manufacturer/Model - Cummins QSF 3.8 (Stage IV/Tier 4final)
Type - Water cooled turbo Diesel
Fuel tank capacity - 210 l
Electrical system - 24V
Alternative Engine
Manufacturer/Model - Cummins QSB3.3 (Stage IIIA/Tier 3)
Type - Water cooled turbo Diesel
Hydraulic system
Driving - Axial piston pump with variable displacement.
Axial piston motors (2) with variable displacement.
Steering - Axial piston pump with variable displacement.
Service brake - 2 multidisc brakes on rear wheels activated by pedal.
Parking/
Emergency brake - Failsafe multidisc brakes in both gear boxes.
