Reticle
Add to favorites
Compare this product
Description
Product overview
Available variants
Common specifications
Applications
- Chrome-on-opal-glass Ronchi ruling slides for testing resolution of reflective optical systems.
- Vacuum-deposited chrome rulings with average optical density >3.0.
- Pattern centered on a nominal 1 x 3 in glass substrate; thickness 1.52 mm.
Available variants
- 5 lp/mm — Stock #59-544
- 10 lp/mm — Stock #59-545
- 20 lp/mm — Stock #59-546
- 40 lp/mm — Stock #59-547
- 80 lp/mm — Stock #59-548
- 100 lp/mm — Stock #59-549
- 120 lp/mm — Stock #59-550
- 150 lp/mm — Stock #59-551
- 200 lp/mm — Stock #59-552
Common specifications
- Pattern Location: Centered
- NIST Certification: No
- Dimensional Tolerance (inches): ±0.100
- Length: 25.40 mm
- Pattern Size: 12.7 x 25.4 mm
- Thickness: 1.52 ±0.100 mm
- Width: 76.20 mm
- Coating: Vacuum deposited chrome
- Substrate: Opal glass
- Optical Density (Average): >3.0
- Surface Quality: 40-20
Applications
- Resolution testing of reflective imaging systems
- Optical metrology and calibration
- Quality control for lenses, mirrors and reflective assemblies
