Duct fan EC series

axialcoolingventilation

Product overview
Axial tube fans of the EC standard series with electronically protected AC‑DC energy‑saving motors, offered in multiple sizes and thicknesses for industrial cooling and ventilation applications.

General description
EC fans provide higher electrical efficiency and longer service life than conventional AC fans thanks to AC‑DC energy‑saving motors and electronic protection. Select models feature selectable speed control for flexible integration.

Specifications

• EC8025 — 80 x 80 x 25 mm (3 x 1 in) — Max airflow: 1.2 m³/min (42 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC8038 — 80 x 80 x 38 mm (3.1 x 1.5 in) — Max airflow: 1.7 m³/min (60 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC9225 — 92 x 92 x 25 mm (3.6 x 1 in) — Max airflow: 1.6 m³/min (56 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC9232 — 92 x 92 x 32 mm (3.6 x 1.25 in) — Max airflow: 1.6 m³/min (58 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC9238 — 92 x 92 x 38 mm (3.6 x 1.5 in) — Max airflow: 2.4 m³/min (85 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC1225 — 120 x 120 x 25 mm (4.7 x 1 in) — Max airflow: 2.3 m³/min (80 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC1238 — 120 x 120 x 38 mm (4.7 x 1.5 in) — Max airflow: 3.8 m³/min (133 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC1551 — 171 x 151 x 51.6 mm (6.7 x 2 in) — Max airflow: 10.2 m³/min (360 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC2060 — 202 x 202 x 60.8 mm (7.9 x 2.4 in) — Max airflow: 14.2 m³/min (500 CFM) — Selectable speed. Electronically protected.
• EC2072 — 206 x 206 x 72.5 mm (8.1 x 2.8 in) — Max airflow: 17.8 m³/min (630 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC2578 — Ø 250 x 78.5 mm (Ø 9.84 x 3.1 in) — Max airflow: 14.0 m³/min (495 CFM) — Selectable speed. Electronically protected.
• EC2578M — Ø 250 x 78.5 mm (Ø 9.84 x 3.1 in) — Max airflow: 13.0 m³/min (460 CFM) — AC‑DC energy‑saving motor. Electronically protected.
• EC2589 — Ø 254 x 89 mm (Ø 10 x 3.5 in) — Max airflow: 23.5 m³/min (830 CFM) — Selectable speed. Electronically protected.
• EC2890 — 280 x 280 x 90 mm (11 x 3.5 in) — Max airflow: 32.3 m³/min (1,140 CFM) — AC‑DC energy‑saving motor. Electronically protected.

Notes

• We reserve the right to change the data without further notice.
• Data performance subject to ±10% tolerance.

Technical specifications

• Series: EC Standard Tube Axial Fans (models: EC8025, EC8038, EC9225, EC9232, EC9238, EC1225, EC1238, EC1551, EC2060, EC2072, EC2578, EC2578M, EC2589, EC2890).
• Construction: mechanical revolving‑blade tube axial fans in multiple diameters and thicknesses.
• Motors: AC‑DC energy‑saving motors (EC type) with electronic protection for extended life cycles.
• Airflow range: approx. 1.2 m³/min (42 CFM) up to 32.3 m³/min (1,140 CFM) depending on model.
• Selectable speed: available on specific models (e.g. EC2060, EC2578, EC2589).
• Tolerances: performance data may vary (±10%).
