Welding fume suction unit BB

dustfor the pharmaceutical industryfor the food industry

Overview
Modular, flexible mobile high-vacuum extraction units designed to protect welders and operators by capturing welding fumes and fine particles close to the source. Compact footprint and caster-mounted frame enable easy movement between workstations.

Key features

• Mobile, compact standalone extraction unit
• Filtration efficiency up to 99.99% for particles ≥ 1 μm
• Operable in vertical or horizontal orientation
• Connections for extraction torches and CHD laminar slit nozzles (300 mm or 2×150 mm)
• Casters and integrated handle for mobility

Benefits

• Efficient capture of welding fumes and dust at source
• Reduced floor space requirement for constrained workshops
• Flexible installation options: vertical or horizontal
• Multiple connection configurations: 1–2 torches or laminar nozzles; recommended one torch per unit for optimal efficiency
• Optional integration of a cyclone cleaner for improved maintenance and filter life

Description
The BB series high-vacuum standalone extraction units combine portability and performance. Their frame with casters and built-in handle allows rapid relocation while minimizing occupied floor area. Units can be positioned vertically or horizontally depending on workshop layout.

Versatile connection options support one or two extraction torches (model-dependent). In accordance with CARSAT recommendations, using a single extraction torch per unit is advised to ensure optimal capture efficiency. Alternatively, connect a 300 mm CHD laminar slit nozzle, two 150 mm CHD hoods, or a cyclone cleaner to match capture and cleaning needs across applications.

Characteristics / technical specifications

• Series: BB range
• Type: mobile high-vacuum standalone extraction unit
• Filtration efficiency: up to 99.99% for particles ≥ 1 μm
• Orientation: vertical or horizontal use
• Connections: 1–2 extraction torches (depending on model); recommended: 1 torch per unit for optimal efficiency
• Compatible accessories: 300 mm CHD laminar slit nozzle, two 150 mm CHD hoods, cyclone cleaner
• Mobility: caster-mounted frame, integrated handle
• Intended sectors: metalworking, fabrication, industrial piping, construction, locksmithing, defense, transportation, chemical, sheet metal and welding workshops
