Raise borer Easer E10 S

Mobile raiseboring machine suitable for conventional raiseboring, boxhole drilling as well as production drilling in drill-and-blast operations in medium to large size drifts Unmatched versatility enabling both upward and downward drilling operations without the need for a concrete platform, adapting easily to diverse site requirements Superior productivity driven by large-diameter drill holes that reduce the risk of ground “freezing”, ensuring uninterrupted and efficient excavation Exceptional accuracy achieved with mechanical rock excavation, delivering less than 1% hole deviation for precise and reliable results Designed to drill opening holes in block cave, sub level caving and sub level stoping mines, this versatile raiseboring rig can also be used for precondition holes, pastefill tube holes and media holes. The rig works in drifts from 4.7x4.7 to 6.0x6.0 m. When drilling with a 750 mm diameter reamer, the Easer L can drill conventional holes up to 200 m and box holes and down reaming holes up to 60 m. The Easer L has the capability to drill angled holes in any direction with a minimum range of 90°–60° from horizontal. The mobile, versatile and productive raiseboring rig Easer E10 S works in drifts from 5x5 to 6x6 m. When drilling with a 750 mm diameter reamer, the Easer E10 S can drill conventional holes up to 200 m and boxholes and downreaming holes up to 60 m. This raiseboring machine has the capability to drill angled holes in any direction with a minimum range of 90°–60° from horizontal. Safety Easer E10 S is designed to keep a high level of safety. One example is the radio remote crane installed to handle drill pipes.
