Eddy current separator SMVT-E5
metalwastecable

eddy current separator
eddy current separator
eddy current separator
eddy current separator
eddy current separator
eddy current separator
Add to favorites
Compare this product


Characteristics

Technology
eddy current
Separated substance
metal, waste, for bulk materials, cable
Application domain
for the recycling industry, for the chemical industry, construction
Other characteristics
automatic, high-efficiency, plastic, raw materials, mining

Description

ERGA SMVT-E5 eddy current magnetic separator provides recovery of fine nonferrous metal particles from nonconductive fractions in processing of raw materials. It is irreplaceable for getting additional profit and clean materials from MSW, cable or plastic waste, WEEE, cullet, scrap, tires, wood chips, slags. - Highly efficient NdFeB magnetic system: SMVT-E5 eddy current separator with eccentric arrangement of high-speed magnetic rotor with rotation frequency up to 5 000 rpm and increased magnetic intensity on the belt surface efficiently remove nonferrous metal particles and their alloys with size from 0.3 mm. Eccentric rotor allows for fine setting of the product separation, as well as for prevention of accumulation of magnetic particles under the belt, thus preventing damage to the shell. Unique patented Nd-Fe-B magnetic systems provide long-term efficient operation. Guaranteed period of magnetic systems properties, subject to operating rules, is 10 years. - Separation/cleaning efficiency up to 99,8%: Customized separation mode is selected depending on feed material. Unique patented system of splitters with accurate position adjustment guarantees precise separation of bulk materials into three streams: conductive, nonconductive and weakly magnetic fractions; - Touch Screen intuitive control and ergonomic design: All digital control is provided from the control panel, which is a 7-inch high-definition touch screen with user-friendly interface. In addition to settings of main operating parameters of the product, it is possible to save settings of separation parameters for every type of material.
