External cylindrical grinding machine TAPOMAT

cutting toolCNCautomatic

The TAPOMAT is characterized by high flexibility, short tooling times, easy operability and a minimal contact surface. A diamond roller (single or multiple tooth) is used to profile the relevant threaded grinding wheel. Diamond fliese tools are used for profiling the chamfer grinding wheel. This allows the machine to grind any optional thread and chamfer shapes. Highlights Single or multiple tooth grinding The patented dressing system permits the production of even minimal thread radii Single or multiple tooth grinding (with or without chamfer) All strokes and shapes can be covered with a single relief cam User-friendly programming Grinding process descriptions HSS tap: M1, spiraled Cycle time: < 60 s Grinding task: Thread profile and chamfer grinding Equipment and Options CONTROL SYSTEM The Erwin Junker Operator Panel was specifically developed to control grinding machines. All machine components are controlled using the operator panel – irrespective of the series and the used control system. The identical structure, intuitive menu guidance and visualization of the workpiece geometry make for extreme user convenience and flexibility in operation. Programming takes place directly using the operator panel or an external programming tool. MACHINE BED The machine bed made of mineral cast provides impressive damping behavior and torsional rigidity. The temperature stability allows fluctuations in the ambient temperature to be compensated with a minimum of effort, ensuring a high level of dimensional stability throughout the whole day.
