Angled ball joint A series
stainless steelsteel

angled ball joint
angled ball joint
angled ball joint
angled ball joint
Add to favorites
Compare this product


Characteristics

Orientation
angled
Material
stainless steel, steel

Description

A Series Ball Joints Medium: Hydraulic, Pneumatic Size: 3/4″ (DN20) – 5″ (DN125) – Style 20 standartd production – Other styles upon request – No lubrication needed – Steel and AISI316TI standard – Other materials upon request – Articulated motion only – ±7.5⁰ angular movement Size: 3/4” (DN20) – 5” (DN125) Material: 42CrMo4, AISI316TI Max. Temperature: (-20⁰C) – (120⁰C) / (-4⁰F) – (+250⁰F) Max. Pressure: 315 bar (4560 psi) Max. Angular Movement: ±7.5⁰ Max. Speed: Very slow speed, articulated motion only
