Cement silo SPR series

terminalpneumatic

Modular Terminals tr_8-1 The Port Terminal of the series SPR is designed and realized for the cement storage. The cement is unloaded, with pneumatic system, from the ships. It is a modular plant composed by one or more silos with rectangular plant. Every silos is endowed with system of extraction of the cement through tubular screw, which can unload on cups elevators or on tilted tubular screw, feeding a loading bellows with capacity about of 330 Ton/hs EUROMECC's engineering office is geared to design your plant according to your needs and to tailor a solution to meet your special requirement. Structure suitable for seismic zone (cat. 2) Cone thickness: 6 mm Corrugated panels thickness: 4 mm Roof thickness: 6 mm Reinforcement profiles: hot rolled FE430-B Loading pipe: external Ø 12"
