AC motor controller SW4A4085C261-00C0380

two-phase stepperprogrammableopen-loop

Principal features ● Vectorial control ● Several fieldbus ● Serial Service for real time programming and debugging Functions ● Wide range of Positioning Control Modes (homing, relative, absolute, target) ● Autonomous management of the firmware for the execution of the homing, of the target movement with relative or absolute quota and for the generation of the ramp profiles ● Torque mode for operation with torque limitation ● Speed control thanks to digital inputs, analogue inputs or fieldbus ● Electronic CAM with advanced programming of internal profiles inside the drive ● Electric shaft with encoder or analogue input with variable tracking ratio (Electric Gear) ● Fast inputs and outputs for motor’ start & stop and event synchronization for high speed response applications such as labeling, nick finder, flying saw etc. ● Possibility to synchronize the movements in multiaxis systems, even without fieldbus ● Enabling and on-the-fly changing of the motion control modes Functionalities Drive control through commands by master controller. Suitable for multi axes systems, built in powerfull Motion Module functionality assures perfect synchronization among axes and reduces master controller workload.
