Gigabit Ethernet slip ring

1 Gbpscapsulefor radar antennas

Overview
Coaxial capsule slip rings provide a protected rotary interface to transfer high-frequency RF signals between stationary and rotating platforms. They maintain signal continuity for analog RF (GHz) and high-speed digital (Gbit) transmissions while minimizing crosstalk and optimizing VSWR for stable signal performance.

Key features and technologies

• High-performance transmission for RF/GHz and Gbit-level data
• Maintains signal integrity by minimizing crosstalk and optimizing VSWR
• Supports analog RF (GHz) and high-speed digital signals (Gbit)
• Gold-to-gold contact technology or contactless transfer options
• Designed for long mechanical life: hundreds of millions of rotations with minimal maintenance
• Capsule housing for increased environmental protection
• Integration capability with other rotary joints (FORJ, hydraulic and high-frequency systems)

Key applications

• Radar and communication systems
• Air traffic control and surveillance installations
• SATCOM antennas and antenna tracking systems
• High-end camera and precision imaging platforms

Technical specifications

• Supported signal types: analog RF (GHz) and digital Gbit signals
• Contact technologies: gold-to-gold contacts or contactless options
• Mechanical life: rated for hundreds of millions of rotations
• Mechanical design: capsule structure for enhanced protection
• Integration: compatible with FORJ, hydraulic and other high-frequency rotary joint systems
