Slip rings with gold contacts

Voltage: 120, 240 V
Primary current: 0 A - 10 A
Rotational speed: 0 rpm - 250 rpm

... The ES Series electrical slip ring is a rotating assembly for transferring analog and digital signals, control circuits and data from stationary inlets to rotating outlets. The compact capsule design ...

Voltage: 0 V - 240 V
Primary current: 0 A - 10 A
Rotational speed: 0 rpm - 250 rpm

... ESM Series electrical slip ring is a compact capsule-style rotating assembly designed to transfer power, control circuits and analog/digital data between stationary inlets and rotating outlets. It features ...

Voltage: 0 V - 240 V
Primary current: 0 A - 10 A
Rotational speed: 0 rpm - 250 rpm

... with combinations of 2 A, 5 A and 10 A power circuits. The series uses gold-on- gold contacts to reduce electrical noise and extend service life. Standard units are available with 8 to 51 circuits. Seals ...

Voltage: 0 V - 24 V
Rotational speed: 0 rpm - 300 rpm
Number of channels: 5 unit

... Product overview
ECN050-14S-01EM-IP65 is a customized low-temperature signal slip ring combining thermocouple, encoder and Ethernet signals. It is designed for industrial automation and control systems where ...

Voltage: 0 V - 500 V
Primary current: 60 A - 800 A
Rotational speed: 0 rpm - 15 rpm

... customized carbon brush slip ring. Carbon brush is made of graphite or carbon-based composite materials, it is fixed at the stationary end and keeps in contact with the slip ring ...

Voltage: 400 V
Primary current: 15 A
Rotational speed: 0 rpm - 50 rpm

... @50Hz (Power); ≥300VAC@50Hz (Signal)
Isolation resistance: ≥500MΩ@500VDC (Power); ≥100MΩ@300VDC (Signal)
Contact material: Gold-to- gold
Housing material: Aluminum alloy
Electrical noise: ≤30mΩ ...

Voltage: 0 V - 20 V
Primary current: 0 A - 1 A
Rotational speed: 0 rpm - 6,000 rpm

... Advantages: ♦10 circuits capsule part ♦Be able to integrate with various signais7 transmission such as USB2.0, HD-SDI, and Gigabit Ethernet ♦High rotating speed up to 6000 rpm ♦Ultra-long service life: 300 million turns ♦Outer Diameter: 25mm ...

Voltage: 240 V
Primary current: 2 A
Rotational speed: 0 rpm - 300 rpm

... capsule slip ring is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical ...

Voltage: 110 V
Primary current: 4 A
Rotational speed: 0 rpm - 300 rpm

... material has been chosen as its housing, and gold to gold contact has been adopted, thus making the slip ring has the feature of stable performance. Besides, the special ...

Voltage: 0 V - 240 V
Primary current: 50 A
Rotational speed: 0 rpm - 1,000 rpm

... diameter: 70mm Outer diameter: 145mm Weight: 3.55kg Construction: through hole, shaft install Electric contact material: Gold- Gold, Fiber brush – Ring Working speed: 0~600RPM Current: ...

Voltage: 0 V - 1,000 V
Primary current: 0 A - 300 A
Rotational speed: 0 rpm - 300 rpm

... parts slip ring rotor & stator seperated


Due to the limited installation size of some customers, our company has developed 2-parts slip ring for customers.


The ...

Voltage: 0 V - 600 V
Primary current: 2 A - 10 A
Rotational speed: 0 rpm - 300 rpm

... 18 / 24 (default 12)
Current per Ring: 2A (signal) / 5A / 10A (optional)
Rated Voltage: 0–380 VAC/VDC (440V / 600V optional)
Max Speed: 300 rpm (up to 600 rpm custom)
Contact Material: Gold- gold ...
