TIG welding machine Microplasma 25-2

plasmamanual230V single phase

The price shown includes the following components: Microplasma welding machine with standard gas metering unit Cool 55 MPW55, “blueCool” coolant to -10 °C (-14 °F), 5 l, 5 l Transport cart (four wheels) for moving a power source, cooling unit or a tool box and two shielding gas cylinders, Two shielding gas cylinders Workpiece lead with clamp, 170 A / 60 %, 16 mm² Gas hose, 2 m Gas hose, Pressure regulator "Maxex", : Cylinder pressure regulator, : Very small, water-cooled, powerful plasma torch, Electrode setting gauge, suitable for PHW 20 Threaded adapter for connecting 1/4" left-hand thread gas hoses to welding machines with 1/4" right-hand connecting nipples, Standard gas metering unit for plasma gas and shielding gas: Plasma gas setting range 0.1 l/min to 0.9 l/min Shielding gas setting range 1.0 l/min to 17 l/min Microplasma welding machine with standard gas metering unit Welding procedures and functions Plasma and TIG welding Plasma and pulsed TIG welding Plasma and pulsed TIG welding up to the kHz range allow a high welding speed with minimal heat input using a constricted arc Plasma and TIG welding current adjustable in 0.1 A increments Pilot arc current separately adjustable for start phase, welding phase, end-crater and welding break Temperature, flow and pressure monitoring for the coolant circuit Non-latched/latched operation Spot welding/tack function (spotArc/spotmatic) Adjustable up-slope and down-slope time Spotmatic – reduce the time required for tacking by up to 50% (TIG only) Adjustable gas pre- and post-flow time
