Ammonia analyzer NH3-Stable

carbon dioxidemonitoringhumidity

Application:  Measuring system for monitoring the ammonia (NH3)-concentration in animal barns  DLG approved (Test report 6768)  Integrated measurement: temperature, humidity, pressure  Maintenance friendly  Installation inside the barn  Options: · Measurement of Carbon Dioxide (CO2), · Switching between two measuring points Features Measuring Procedure: Discontinuous measurement including automatic flushing / filter system for long-term stable measurements. Measuring Cycle: Time between two measurements: 1 and 12 hours (adjustable); constant output of measured values during measuring pauses Transmitter (Standard):  NH3-Stable with measuring range 0…200 ppm NH3  Lifetime > 1 year (DLG-Test report 6768 recommends change of sensor element every six months) Flushing-/Filter-System: Filter simply exchangeable and lifetime of over one year Integrated Measurement: Temperature (T), relative humidity (r. H.), absolute pressure (p) Transmitter (Option): CO2-5000-IR4 with measuring range 0…5000 ppm CO2 Measuring Points: 1 (Standard) and/or 2 including switching between measuring points (as Option) Operation Temperature: -10 °C to +40 °C Storage Temperature: -25 °C to +60 °C (system not in operation)
