Aluminum profile crimping machine
automatichydraulicPLC-controlled

aluminum profile crimping machine
aluminum profile crimping machine
Add to favorites
Compare this product


Characteristics

Product handled
for aluminum profiles
Operational mode
automatic
Drive type
hydraulic
Other characteristics
PLC-controlled, vertical

Description

4 point crimper (Vertical) Standard Features • Steel plate with high pressure resistance • Automatic positioning with servo system • Touchscreen • Adjustable clamping system for high profiles • Adjustment of crimping blades based on profile • Hydraulic operating system • Two stage hydraulic pressure setting in assembly • Safe working area with safety barrier • PLC control system • Strong hydraulic pump system • Precision assembly process with robust brake system Optional Features • Crimping set for custom profiles • Barcode reader Technical information • Voltage : 400V (Can be customized to 600V, 220V or other with transformer) • Minimum size (WxH) : 515 mm – 515 mm • Maximum size (WxH) : 2000 mm – 3400 mm • Travel distance 40 mm • Distance between blades 100 mm • 5 mm crimping blade set 8 pcs

VIDEO
