Concrete cutter MPF320

Presentation
Aluminium wall saw designed for single-operator use and easy installation. The machine is split into two sections for transport and mounting: first section 28 kg, second section 36 kg. Motor-to-blade transmission uses a double-chain pinion. Electrical panel is supplied in a separate metal enclosure and motor protection is included. Control voltage 24 V. Option available for fitting diamond wire cutting equipment.

Technical specifications

• Model: MPF320
• Model code: PTEMPF320
• Applicable blade diameter (mm): 800 – 900
• Maximum cutting depth (mm): 330 – 380
• Cut feed: Manual
• Depth feed: Manual
• Motor power (kW (Hp)): 5.9 (8.0)
• Supply voltage (Volts): 400
• Starting: Star–Delta
• Rail length (mm): 600
• Split for mounting: first part 28 kg, second part 36 kg
• Transmission: motor – blade with double-chain pinion
• Electrical panel: separate metal enclosure
• Protection: thermal motor protection
• Control voltage: 24 volts
• Option: diamond wire cutting equipment

Installation and handling

• Designed for single-operator assembly on site
• Split sections facilitate transport and positioning
• Mounting on provided rail (600 mm) recommended
• Check electrical supply: 400 V main and 24 V control circuit
• Regular inspection of chain tension and mechanical fastenings before use

Options and safety

• Optional kit for diamond wire cutting
• Motor thermal protection and separate electrical enclosure for safety
• Emergency stop and control interlocks recommended
• Use appropriate PPE and follow local safety regulations
• Periodic maintenance schedule for chains, drive and electrical components
