Jaw crusher MTH500

stationaryfor building materialsstone

Overview
Double-shaft crusher designed for crushing construction materials including asphalt slabs, very hard rock, reinforced concrete blocks and granite. Equipped with two counter-rotating shafts fitted with high-resistance steel blades. Machine operates at low shaft speed to limit dust and noise. Fully automatic with anti-locking system that reverses blade rotation to clear jams and prevent blockages.

Applications

• On-site recycling of construction and demolition waste
• Crushing of asphalt, concrete, granite and natural rock
• Preparation of material for reuse or further processing

Key features

• Two-shaft design with special steel blades
• Automatic anti-locking system with direction reversal
• Controlled low-speed rotation to reduce dust and noise
• Selected output grain size approximately 0–50 mm (0–5 cm)

Technical specifications

• Model: MTH500
• Model code: PFRANIDE
• Electric motor: 400 V, 50 Hz
• Power: 7.35 kW (10 HP)
• Feed opening: 490 x 390 mm
• Expanded loading hopper: 1000 x 1140 mm
• Hourly capacity: 4–8 m3/h
• Weight: 800 kg
• Overall dimensions: 780 x 2200 x 1500 mm
• Screens: two plates 575 x 760 mm with holes 22 x 22 mm and 6 x 6 mm, wire Ø 3 mm

Options

• Vibrating screen for grading material sizes
• Customized screen configurations and service kits
