Platform semi-trailer HighwayMAX Booster

low-loadergooseneckself-tracking

The 12-axle HighwayMAX Booster single drop highway trailer is pushing the legal payload of this unique transport system towards 205,000 lbs at 20,000 lbs per axle! With its very strong spine and the Pin-on Nitro booster, the HighwayMAX Booster can handle even concentrated loads with ease. The wheel bogies has been reinforced in order to allow the lifting of the booster under full payload. Closed and with the booster decked, the truck & trailer length remains below 90’. For higher payload capacity Outstanding maneuverability & fast mobilization Pin-on Nitro booster, easy to connect and to remove Booster in self-tracking pivot design with additional steering cylinder Main trailer with king-pin steering Steering angle up to 60° Time-saving & user-friendly Stretch deck with a total length of 89’ without booster Easy extending and closing within minutes “Truck & Trailer” length below 90’ allowing to travel without escort in most states Axle spacing between the groups adjustable up to 16' with booster and up to 22’-6” without booster in steps of 2' All axles liftable Trailer and booster with self-contained power packs Even stronger than an ox Extremely high point loads of 44,000 lbs over axle bearings and 88,000 lbs over center spine Concentrated load capability even for extended loading platform Hydraulic axle compensation for increased side stability Multiple lashing rings and load fixing points The peak of high-tech US-DOT certified components for brake- and lighting system Spare parts available in the US market Fully metalized /spray galvanized trailer for the best corrosion protection available in the market
