Small parts storage chest of drawers Orga 4504M

Description
The Orga Mobile 4504M is a mobile ESD drawer unit engineered for EPA zones and electronic production areas where electrostatic protection and organized, mobile storage are required. Constructed from conductive steel with a powder-coated finish (RAL 7035 Light Grey) to ensure static dissipation and long service life.

Main features

• Conductive steel mobile unit with powder coating (RAL 7035)
• Four full-extension drawers with telescopic runners for easy access
• Four swivel casters Ø 50 mm for mobility (two casters with brakes)
• Central cylinder lock for secure access control
• Individual drawer load capacity: 25 kg (total 75 kg)

Technical specifications

• Model: Orga Mobile 4504M
• Brand: FORISON
• Material: Conductive ESD steel, 1.0 mm
• Finish: Powder-coated (RAL 7035 Light Grey / optional RAL 7016 Anthracite)
• External dimensions (W × D × H): 450 × 487 × 565 mm
• Drawer usable dimensions (W × D × H): 366 × 441 × 91 mm
• Number of drawers: 4
• Drawer load capacity: 25 kg each
• Total load capacity: 75 kg
• Casters: 4 swivel Ø 50 mm (2 with brakes)
• Runners: Telescopic, full extension
• Weight: 29 kg
• ESD compliance: IEC 61340-5-1

Applications

• EPA and electronics production areas for safe storage of sensitive components and tools
• Workshops and maintenance areas for organized tool storage
• Laboratories, inspection stations and assembly lines requiring mobile, grounded storage

Delivery & warranty

• Estimated lead time: 2–3 weeks
• Warranty: 5 years
• Options & customization: available on request (color, accessories)
