Drying oven XM06curingpolymerizationpowder coating

drying oven
drying oven
drying oven
Add to favorites
Compare this product
indicative price

Characteristics

Function
drying, curing, polymerization, powder coating
Configuration
chamber
Heat source
electric
Other characteristics
high-volume
Capacity

6,000 l (1,585 gal)

Maximum temperature

200 °C (392 °F)

Description

XM range – Modular ovens Our range of XM ovens is ultra-modular, their size is adapted to the size of the product. These ovens are adapted to composites curing, polymerization, coating and drying applications. Advantages: Modularity for a perfect adaptability Maximum 200°C (up to 300°C as an option) Exclusive ventilation system Excellent temperature uniformity Long-life robust materials French manufacturing Exclusive modular design Modules The basic XM oven is composed of a front double leaf door (with safety inner handle), a module and a back part. The internal and external sheets are made of electrogalvanized steel. The external sheets are coated with white and blue epoxy paints. 3 light points per module activated at doors opening. The manufacturing with modules reduces manufacturing costs resulting in very affordable prices for the customer. Excellent temperature uniformity Thanks to their exclusive ventilation system and to their efficient heating system, our XM ovens guarantee excellent temperature uniformity. Working volume’s air is sucked by the impeller, is reheated by the heating elements then is blown into the working volume. Heating is ensured by heating elements, ideally placed in the air flow. Depending on the module, the heating power is between 33kW and 88kW. The maximum temperature is 200°C (consult us for higher max temperature). The thermal insulation by asbestos-free glass wool is optimized.
