VHF antenna FA-3 seriesomnidirectionaloutdoormobile
Add to favorites
Compare this product
Characteristics
- Network
- VHF
- Type
- omnidirectional
- Other characteristics
- outdoor, mobile
- Frequency
Min.: 156 MHz
Max.: 163 MHz
- Gain
3 dB
Description
Bandwidth----------------------------------- 5 MHz within 2.0:1 VSWR
Impedance---------------------------------- 50 Ohm
VSWR---------------------------------------- nominally 1.5:1 at 159.5 MHz
Polarization--------------------------------- Vertical
Maximum Power Input-watts--------- 50W
Horizontal Beam Width---------------- 360º
Vertical Beam Width-------------------- 58º
DC Ground---------------------------------- No DC Ground
The antenna will read open on continuity test.
Height----------------------------------------- 1150±10 mm
Radome Material-------------------------- Fiberglass
Ferrule----------------------------------------- POM
Coax Supplied------------------------------ RG-58U(white),4.5m
Connector------------------------------------ PL259, Loosen
Weight----------------------------------------- 420g
