Oil dehydration unit CMM-1H

The СММ-1Н unit is designed for drying1, heating2 and filtration3 of mineral transformer oil4, as well as evacuation of transformer5 tanks. The process is based on application of heat and vacuum6. The oil is heated and pumped to the vacuum chamber. The low pressure in the chamber makes the water in the oil boil and evaporate. The water vapor is removed with vacuum pump exhaust. The СММ-1Н unit consists of the following elements: a frame, a centrifugal oil pump (output), a vacuum pump7, an electrical control cabinet, a vacuum chamber, filters8, an oil trap, piping, an instrument panel, an oil inlet and an oil outlet. the unit is equipped with a centrifugal output pump to reduce noise; the unit does not have an input pump, the oil goes directly into the unit with reduced risk of leaks; simple operation; a porous inset in the vacuum chamber facilitates efficient moisture separation; the smart heating system varies current for the required processing rate, eliminating voltage surges; a water condensate collection container is installed; the unit features a separate outlet for transformer evacuation.
