Cable stripping and crimping machine CF3000 - 2,5
automaticpneumatic

cable stripping and crimping machine
cable stripping and crimping machine
cable stripping and crimping machine
cable stripping and crimping machine
cable stripping and crimping machine
cable stripping and crimping machine
cable stripping and crimping machine
Add to favorites
Compare this product


Characteristics

Product handled
cable
Operational mode
automatic
Drive type
pneumatic
Crimping capacity

8 mm (0.3 in)

Description

The STRIPPING AND CRIMPING MACHINE CF 3000-2,5 is used for the processing of FERRULE in bandware version with insulating collar in accordance with DIN 46 228-4. With STRIPPING AND CRIMPING MACHINE CF 3000-2,5 it is possible to push and hold strands in a single operation up to 1200 conductors per hour and can be equipped for different sections in only one minute, both pre-packing and direct fixing of the conductors in the electrical cabinet. Technical features: ALIMENTATION - Monophase 120 VAC/60 Hz PNEUMATIC ALIMENTATION - No ABSORBMENT - 160 VA STRIPPING LENGTH - Till to 8 mm / Cycle Time 1,2 s WORKABLE SECTIONS - 0,05÷2,5 mm² WORKABLE DIAMETER - Depends On The Material WORKABLE CABLE - PVC-Teflon-Silicon-Similar MIN STRIPPING LENGTH - 49 mm TOLERANCE - <= 0,002 xL (L=Stripping Length) DISPLAY - LCD Liquid Cistal Display MEMORY - No WEIGHT - 12 Kg DIMENSIONS - 320x300x165 mm (WxDxH)

VIDEO
