cable stripping and crimping machine / automatic / pneumatic
CMT78

{{requestButtons}}

Characteristics

  • Product handled:

    cable

  • Operational mode:

    automatic

  • Drive type:

    pneumatic

  • Crimping force:

    20,000 N

Description

The STRIPPING CRIMPING UNIT CMT78 is a semiautomatic bench unit suitable for simultaneously stripping and crimping single-core cables (minimum length 70 mm) or multi-core cables with minimum unsheathing length of 20 mm. The machine permits avoiding costly stripping operations, especially on cables where stripping must necessarily be manually repeated.

Moreover, the sensor cycle start system ensures perfect crimping with excellent cable positioning.

The parameters are entered by means of an intuitive touch-screen graphic interface.

The STRIPPING CRIMPING UNIT CMT78 can also be used as a traditional crimping machine (cable already stripped) or, when requested, as a stripping unit only.

The STRIPPING CRIMPING UNIT CMT78 comes complete with protection guards-safety devices and instruction manual and is built in conformity with applicable safety regulations.



Technical features:
DIMENSIONS860X500X450 mm
WEIGHT110 KG
POWER SUPPLY230 V 50-60Hz
MOTOR POWER0.75 KW
STROKE40 mm
CRIMPING FORCE2,000 KG (20,000 N)
WORKING CABLEFrom 0.12 mm2 (26AWG) to 2.5 mm2 (14AWG)
