Pneumatic stripping machine GM45

for electrical cablesbench-topsemi-automatic

The STRIPPING MACHINE SHORTEN PHASES GM45 is a bench modular pneumatic unit highly recommended for the semi-automatic processing of unipolar and multipolar cables. The system can be equipped with 3 series of blades, thus allowing for three different operations without any special intervention on the machine. An appropiate combination of the blades makes the following operations possible: Stripping of one or more unipolar cables Stripping of multi-polar cables Cutting with the resultin stripping of several cables The STRIPPING MACHINE SHORTEN PHASES GM45 comes complete with protection guards, safety devices for accident prevention and instruction manual. ALIMENTATION - No PNEUMATIC ALIMENTATION - 6 Bar ABSORBIMENT - No STRIPPING LENGTH - 1÷50 mm MAX SECTION - Depends on the Material WORKABLE CABLE - PVC-Teflon-Silicon-Similar MIN CABLE LENGTH - 15 mm + Strip TOLERANCE - <= 0,002 xL (L=Stripping Length) DISPLAY - No MEMORY - No WEIGHT - 21 Kg DIMENSIONS - 200x400x400 mm (WxDxH)
