The TWISTING MACHINE GM WK-20 machine is an ideal device for twisting wires and cables.
Loading by the operator is manual and the start of the TWISTING cycle is via a pedal actuator.
The ends of the wires can be already stripped or complete with terminals even with a rubber pad assembled.
The operation of the TWISTING MACHINE GM WK-20 is electric with electronic setting of all parameters in a simple and fast way with storage of the same on various recipes.
Alimentation - Monophase 230V 50/60 Hz
Pneumatic Alimentation - No
Absorbment - 200 W
Working Capacity - Till to 20 Wires Diameter 1,2 mm
Start - Pedal
Number of Twisting - Till to 10.000
Workable Material - Used in Many Sectors
Productivity - 200÷5.500 cycle/min
Display - Numeric Viewer
Memory - 99 Programs
Weight - 20 Kg
Dimensions - 1200x220x310 mm (WxDxH)
