Automatic twisting machine GM2 TWIST

The CUTTING AND STRIPPING AND TWISTING MACHINE GM2 TWIST is electronic and suitable for the automatic processing of unipolar cables with a diameter up to 5 mm. The CUTTING AND STRIPPING AND TWISTING MACHINE GM2 TWIST has an electric operation with fully electronic setting of all the processing parameters. The peculiarity of the CUTTING AND STRIPPING AND TWISTING MACHINE GM2 TWIST is that of being able to CUT, STRIP and TWIST the UNIPOLAR ELECTRIC WIRES in a single step in a simple and precise way. The CUTTING AND STRIPPING AND TWISTING MACHINE GM2 TWIST has the capacity to memorize up to 99 programs, and is supplied complete with all accessories, protections, instruction manual and programming manual. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - 6 Bar ABSORBIMENT - 300 W STRIPPING LENGTH - Front 0,1÷99 mm – Back 0,1÷99 mm TWISTING LENGTH - Front 0,1÷99 mm – Back 0,1÷99 mm WORKABLE SECTIONS - 4÷32 AWG - Max Diameter 5 mm CUTTING LENGTH - 1 mm÷100 m FEEDING - 2 Drive Motors WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - L = 100 mm, 2.000 – 5.000 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Touch Screen Display LCD Liquid Cristal MEMORY - 99 Programs WEIGHT - 39 Kg DIMENSIONS - 560x680x360 mm (WxDxH)
