Resistance soldering machine M558

automatic

The SOLDERING WELL GM M558 complies with the European directive No. 2003/95 / EC Rohs of 2006, which indicates that it is not possible to use harmful substances such as Lead. It is therefore necessary to use new types of tin alloys that do not contain lead in the welding procedures. Therefore, new types of titanium crucible pits have been developed such as the SOLDERING WELL GM M558. The SOLDERING WELL GM M558 offers greater wear resistance created by the new alloys. TEMPERATURE Da 200° a 600°C DIMENSIONS OF THE CRUCIBLE 55 x 55 x 45 mm CRUCIBLE MATERIAL Titanio ALIMENTATION 230V 50-60HZ MONOFASE - 1 PHASE DIMENSIONS 266 x 145 x 115 mm CAPACITY 1,2 Kg
