The TYING MACHINE GM144 is a bond that allows to tie together with the plasticized metal wire various types of material starting from a thickness of 5 mm to reach a maximum of 90 mm.
This is an ELASTIC BINDER, the TYING MACHINE GM144 binding models are proposed to the end user depending on the thickness of the materials to be tied:
- TYING MACHINE GM144 mod. S = from 5 to 30 mm
- TYING MACHINE GM144 mod. M = from 15 to 45 mm
- TYING MACHINE GM144 mod. L = from 30 to 70 mm
- TYING MACHINE GM144 mod. XL = from 40 to 90 mm
ALIMENTATION - Monophase 230 V 50/60 Hz
PNEUMATIC ALIMENTATION - No
ABSORBMENT - 200 W
BINDING DEPTH - Depends
START - Automatic
DIAMETER OF THE MATERIAL TO TIE -
Model S 5÷30 mm
Model M 15÷45 mm
Model L 30÷30 mm
Model XL 40÷90 mm
WORKABLE CABLE - PVC-Teflon-Silicone-Vetro
DISPLAY - LCD Liquid Cristal Display
MEMORY - No
WEIGHT -
Model S 40 Kg
Model M 40 Kg
Model L 50 Kg
Model XL 50 Kg
DIMENSIONS -
Model S 400x300x400 mm (WxDxH)
Model M 400x300x400 mm (WxDxH)
Model L 400x350x550 mm (WxDxH)
Model XL 400x350x550 mm (WxDxH)
