Cable stripping machine GM204electricbench-toppneumatic
Add to favorites
Compare this product
Characteristics
- Product to be stripped
- cable
- Other characteristics
- electric, bench-top, pneumatic
- Diameter
Min.: 0.4 mm
(0.02 in)Max.: 5 mm
(0.2 in)
Description
The STRIPPING AND TWISTING MACHINE GM204 is an economical machine capable of STRIPPING and TWISTING CABLES.
The STRIPPING AND TWISTING MACHINE GM204 has electric and pneumatic operation and is a highly flexible bench machine suitable for STRIPPING and TWISTING CABLES with all types of insulation.
The machine is supplied complete with instruction manual and CE certifications.
ALIMENTATION - Monophase 230 V 50/60 Hz
PNEUMATIC ALIMENTATION - 6 Bar
ABSORBIMENT - 30 W
STRIPPING LENGTH - 3÷45 mm
WORKABLE SECTIONS - Depends on the Material
WORKABLE CABLE - PVC-Teflon-Silicon-Similar
MIN CABLE LENGTH - 22 mm + Strip
TOLERANCE - <= 0,002 xL (L=Stripping Length)
DISPLAY - No
MEMORY - No
WEIGHT - 5 Kg
DIMENSIONS - 320x170x180 mm (WxDxH)
