Bending cutting machine GM6P

knifefor PVCfor glass

The CUTTING AND STRIPPING AND BENDING MACHINE GM6P is an electronic machine suitable for the automatic processing of single-core wires up to a section of 6 mm2. The CUTTING AND STRIPPING AND BENDING MACHINE GM6P has electric operation with totally electronic setting of all processing parameters. The CUTTING AND STRIPPING AND BENDING MACHINE GM6P allows you to perform the cutting, stripping and bending of rigid unipolar wires, it allows you to create bends as you like such as W, Z or U, it is widely used for U jumpers having to cut lengths short and having to strip them for a length of 5 mm for example, you can set the parameters you prefer. The CUTTING AND STRIPPING AND BENDING MACHINE GM6P gives you the possibility of memorizing up to 100 programs, rapid setting of all processes via LCD touch screen display The CUTTING AND STRIPPING AND BENDING MACHINE GM6P is supplied complete with all accessories, instruction manual and complete with CE certifications. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - 6 Bar ABSORBMENT - 350 W STRIPPING LENGTH - Front 0,1÷50 mm – Back 0,1÷50 mm WORKABLE SECTIONS - 0,1÷6 mm² CUTTING LENGTH - 1 mm÷100 m BENDING RANDIAN - Customized Upon Request BENDING LENGTH - Illimitate BENDING TYPE - Clockwise, Counterclockwise, Deflection Adjustable, Any Angle BENDING CYCLES - 10 Segments Max FEEDING - 2 Drive Motors WORKABLE CABLE - PVC - Teflon - Silicon - Glass PRODUCTIVITY - L = 100 mm, 2.000 – 5.000 pezzi/h CUTTING TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - 7” Touch Screen Schermo LCD Liquid Cristal Display MEMORY - 100 Programs WEIGHT - 30 Kg
